3-2-3 Quality, minimum section and maximum length of cables
• The cable connected to the output terminals of the generator must be selected in accordance
with local regulations. The type of cable must be determined by its rated voltage and current,
current carrying capacity, installation conditions, stress and ambient temperature.
• For flexible wiring, rubber-sheathed, flexible core conductors of the type H07 RN-F (Cenelec HD.
22) or better must be used. As an example, the following table indicates the maximum allowable
3-phase currents in an ambient of 40℃ for cable types and wire sections as listed in accordance
with VDE 0298.
Local regulations remain applicable if they are stricter than those proposed below.
Max. allowable 3-phase current (in A) for PVC insulated conductors, multiple or single core;
H07 RN-F multiple core
Wire size mm
2
10 16 25 35 50 70 95 120
Multiple core 52 70 92 114 138 176 212 245
Single core 57 77 103 126 153 195 236 273
Allowable current(A)
H07RN-F 50 76 88 110 138 170 205 239
These values determine the lowest acceptable wire section (in mm
2
) of multiple core cable or
H07 RN-F and the corresponding maximum length (in m) of cables for a voltage drop of e <_ 5%,
at rated current and at a power factor of 0.80.
Min. section (in mm
2
) and max. cable length (in m)
DCA type 70 125 180
Rated current (A) 91 152 228
Minimum section (mm
2
) 35 70 120
Maximum length (m) 237 284 325
Relations between min. section (in mm
2
) and max. cable length (in m)
Equation for voltage drop of 3-phase, 3-wire system obtained from cable length and operating current:
voltage drop, e (V) = 30.8×L×I
1000×A
e = Voltage drop (V)
L = Length of one wire (m)
I = Generator rated current (A)
A = Wire size (mm
2
)
If connected to receptacles;
Receptacle (A)
(No.)
16
X 24
32
X 23
63
X 22
125
X 21
Minimum section (mm
2
) 1.5 6.0 16 35
Maximum length (m) 28 115 125 199
