DEPA
®
Air Operated Diaphragm Pumps
8.0 Spare Parts
8.1 Spare parts storage
Sincetheextentoftherecommendedspare
parts storage depends on the period of use
andthedierentoperatingconditionsforthe
pumps, you should consult the manufactur-
er or an authorized dealer.
8.2 Ordering spare parts
Please state the following when ordering
spare parts:
■
Pump type
■ Construction year and serial number
■ Spare parts article number
Should subsequent material changes for dif-
ferent parts of the pump have taken place,
this information is mandatory. The required
spare parts and their article numbers can be
found in the spare parts lists. These can be
found under www.cranecpe.com.
Liability when using non-genuine spare
parts:
The installation and/or use of non-genuine
spare parts or accessories can have a neg-
ativeeectondesignfeaturesoftheairop-
erated diaphragm pump and thus adversely
aectitsoperation.Fordamagecaused
by the use of non-genuine spare parts and
accessories on pump, system or product all
liabilityandwarrantyisexcluded.
8.3 Spare parts kits
MINI spare part kit
Pump type all
Pump size all
Item Quan-
tity
Diaphragm 30 2
●
Flat gasket air chamber/con-
trol block and
control block cover
(interior valve)
51
2
(1 piece
at
DH15-
FA)
●
Flat gasket air chamber/con-
trol block and control block
cover
(exterior valve)
51Q 2 ●not
size 15
Glide ring + O-ring 65 1 + 1
(size
15x2)
●not
size 15
O-Ring ((valve-) housing) 16 4 --
O-ring (exterior diaphragm
plate)
38 2 --
O-ring 31 8 --
O-ring air filter 68 1 --
O-ring air inlet 681 1
●not
size 15
O-ring control block cover 51-1 1
●not
size 15
O-ring control block cover 51-2 1
●not
size 15
O-ring control block cover 51-3 1
●not
size 15
O-ring control block cover 74 1
●size 80
only
O-ring T-piece 20 4 --
