DEPA
®
Air Operated Diaphragm Pumps
MEDI spare part kits
Spare part kit type G M P S U X A
Pump type DL-PM DL-SA/SX/
CA/CX/SS
DL-PP/PL DL-SLV DL-SUV/
UEV
DH-TP/
TPL
DH-FA /
SA/SS
Pump size 15/25/40 15/25/40/
50/80
15/25/
40/50/80
25/40/
50/80
25/40/
50/80
15/25/
40/50
15/25/40/
50/80
Item Quan-
tity
Diaphragm 30 2
● ● ● ● ● ● ●
valve seat 31 4
● ● ●
-- -- --
●
Valve ball 32 4
● ● ● ● ● ● ●
Spring washer 40 2
●
--
●
-- -- -- --
Flat gasket air chamber/
control block and control
block cover (interior valve)
51 2
● ● ● ● ● ●
●size 15
only
Flat gasket air chamber/
control block and con-
trol block cover (exterior
valve)
51Q 2 --
●not type
SS
-- -- -- -- --
Shaft bearing 64 2
● ● ● ● ● ●
--
Shaft bearing 64 1 -- -- -- -- --
● ●
Glide ring + O-ring 65 1
Nom-
inal
width
15,
2 Qty
● ● ● ● ● ● ●
O-Ring ((valve-) housing) 16 4
●size 40
only
--
●
-- --
●
--
O-ring (exterior dia-
phragm plate)
38 2
●not
size 15
-- ●not size
15
-- -- -- --
O-ring 31 8 -- -- --
● ●
-- --
O-ring air filter 68 1 --
●not size
15
--
● ●
-- --
O-ring air inlet 681 1 --
● ● ● ●
-- --
O-ring control block
cover
51-1 1 -- -- -- -- --
●not
size 15
●not
size 15
O-ring control block
cover
51-2 1 -- -- -- -- --
●not
size 15
●not
size 15
O-ring control block
cover
51-3 1 -- -- -- -- --
●not
size 15
●not
size 15
Muffler solenoid valve
control block
78M 1 -- -- -- -- -- --
●
O-ring control block 74 1 -- --
●DL80-
PP only
-- -- -- --
O-ring T-piece 20 4 -- -- -- --
●
-- --
Product header seal 22 2 -- -- --
● ●
-- --
Spare part kit type M
Spare part kit type A
R
19
23
25
31
32
50
13
90
11
21
30Z
01
80
77
51-2
51-3
51-1
69
45
65-2
64
02
25
65-1
30
47
46
23
25
70
23
78
79
31T/R
78 only DL50/80-SS/HS
DL25/40-SS-Q only
A-valve
DEPA E4
®
composite membrane
