Derby cycle Pedelec Impulse Evo - Basic Functions Overview

EN-18 Original User Guide | Pedelec Impulse Evo Version 1
1
2
3
4
Easy-reach control
NO. SYMBOL FUNCTION
1 ON/OFF
 3.3.1 Switching on the Pedelec Page EN-19
 3.3.2 Switching off the Pedelec Page EN-19
2
a) Increase value / scroll up
b) Push assist  3.3.5 Using push assist Page EN-21
c) Enable display light for 30 seconds
3
a) Reduce value / scroll down
b) Enable display light for 30 seconds
4
a) Congure/conrm
b) In the main menu, switch between the SET favourites
 3.3.6.1 Display of SET favourites in the start menu Page EN-21.
c) Enable display light for 30 seconds
3.3 Overview and basic functions
0
.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip time
0
.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
0
.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
SPORT
POWER
1 2 3
5
7
6
4
USB power jack
(only on Impulse Evo Smart display)
Impulse Evo Smart display / Impulse Evo display
NO.
FUNCTION
1
Battery charge level + remaining range
2
Time  3.4.2.9 Time Page EN-29
3
Assist mode  3.3.4 Changing assist mode Page EN-20
4
Assist display  3.3.4 Changing assist mode Page EN-20
5
SET favourites  3.3.6 SET favourites Page EN-21
6
Speed
7
Light
