EN-46 Original User Guide | Pedelec Impulse Evo Version 1
Recommended charge
temperature
+10 to +30°C +10 to +30°C
Operating temperature
-10 to 45˚C -10 to 45˚C
Recommended storage tem-
perature
+18 to +23°C +18 to +23°C
* * 3 LEDs up to wear limit in consideration of battery age
** 4 A charger up to 95% FCC
*** For the lowest assist level under optimal conditions and with a fully charged battery of the
highest capacity
5.3 Overview and basic functions
LabelBMS
(battery management
system)
Power jack Protective cap for
power jack
5.2 Technical details
Type
15 Ah 17 Ah
Position
Seat tube Seat tube
Part number
170516014
Nominal capacity
14.25 Ah
Nominal voltage
36 V
Power
520 Wh
Weight
3120 g
Charge cycles*
1,100 full cycles
Charge time**
Approx. 3.5 hours
Cell
Li-ion
Range***
180 km
Permitted charge temperature
0 - 45˚C
170516015
16.75 Ah
36 V
630 Wh
3185 g
1,100 full cycles
Approx. 4 hours
Li-ion
205 km
0 - 45˚C
