EN-56 Original User Guide | Pedelec Impulse Evo Version 1
6.3.1 Charging a battery
A battery can stay tted to the Pedelec for the charging
process. It can also be removed and charged elsewhere.
Charger 1:
1. Plug the mains connector into a socket
2. Remove the protective cap on the battery
3. Connect the charger cable to the battery (it clicks into place)
4. When the charge process has nished, unplug the charger cable from
the power jack of the battery
5. Unplug the connector from the socket
Charger 2
Charger connected to
power supply
| the green LED ashes
Battery being charged
| the green LED ashes
Fully charged
| the green LED continually ON
Charging fault
| the red LED ashes
Charging display
Charger cable
