6.3.1.1 Battery display during the charge process
Display Description Charge level

5 LEDs are ON and no LED ashes 100 - 97%


4 LEDs are ON and the 5th LED ashes 80 – 96%


3 LEDs are ON and the 4th LED ashes 60 – 79%


2 LEDs are ON and the 3rd LED ashes 40 – 59%


1 LED is ON and the 2nd LED ashes 20 – 39%

1 LED ashes 0 – 19%
Charger 2:
1. Plug the mains connector into a socket. The green LED ashes.
2. Remove the protective cap on the battery
3. Connect the charger cable to the battery. The LED ashes at a constant
rate
and indicates that the charge process has started.
4. The charger switches o once the battery is fully charged. The green
LED lights continually
.
5. When the charge process has nished, unplug the charger cable from
the power jack of the battery
6. Unplug the connector from the socket
