Det-Tronics UD10 User Manual

21 95-86614.1
orDerinG informAtion
Sensor module, transmitter module and termination
boxes (if used) must be ordered separately.
Refer to the UD10 Model Matrix for ordering details.
REPLACEMENT PARTS
Part Number Description
009700-001 Magnetic Tool
010569-001 Electronics Module - Relay/4-20 mA
010550-001 Electronics Module - Foundation Fieldbus
101197-001* Stop Plug, 3/4” NPT, AL
101197-004* Stop Plug, 3/4” NPT, SS
103517-001 Stop Plug, M25, AL, IP66
101197-003 Stop Plug, M25, SS, IP66
010816-001 Stop Plug, 20PK, 3/4” NPT, AL
010817-001 Stop Plug, 20PK, 3/4” NPT, SS
010818-001 Stop Plug, 20PK, M25, AL, IP66, EXDE
010819-001 Stop Plug, 20PK, M25, SS, IP66, EXDE
102804-001 Reducer, M25 to M20, AL
102804-003 Reducer, M25 to M20, SS
103922-001 475 Field Communicator
102868-001 Lubriplate grease, 14 oz.
005003-001 Lubriplate grease, 1 oz.
010268-001 Gas Inspector CD
010204-001 W6300G1003 Gas Inspector Connector
*NEMA 4/IP66 rating requires addition of non-hardening
thread sealant or Teflon tape.
ASSISTANCE
For assistance in ordering a system to meet the needs
of a specific application, please contact:
Detector Electronics Corporation
6901 West 110th Street
Minneapolis, Minnesota 55438 USA
Operator: (952) 941-5665 or (800) 765-FIRE
Customer Service: (952) 946-6491
Fax: (952) 829-8750
Web site: www.det-tronics.com
E-mail: det-tronics@det-tronics.com
UD10 MODEL MATRIX
MODEL DESCRIPTION
UD10 Universal Display Unit
TYPE MATERIAL
A Aluminum
S Stainless Steel (316)
TYPE THREAD TYPE
5M 5 Port, Metric M25
5N 5 Port, 3/4" NPT
TYPE OUTPUTS
25 Relay, 4-20 mA, RS485, HART
27 Relay, 4-20 mA, FOUNDATION
™
Fieldbus, HART
28 EQP / DCU Emulator
TYPE APPROVAL
A FM/CSA
B INMETRO (Brazil)
C CSA
W FM/CSA/ATEX/CE/IECEx
TYPE CLASSIFICATION (Div/Zone)
2 Ex d (Flameproof)
TYPE OPTIONAL CONDITIONING BOARD
(Blank) None
C CGS
N NTMOS
