Det-Tronics UD10 User Manual

4.1 95-8661K-2
C706X SENSOR
BLACK
RED
GREEN
SEE NOTE 1
NOTE 1 CONNECT THE GREEN SENSOR LEAD
TO THE CHASSIS GROUND LUG ON THE
INSIDE BOTTOM OF THE DISPLAY ENCLOSURE.
NOTE 2 UD10 HOUSING MUST BE ELECTRICALLY
CONNECTED TO EARTH GROUND.
UD10
DISPLAY UNIT
C2422
Sensor Connector
Power Supply Connector
Output Loop
Connector
MODBUS
Connector
Relay Connector
P1
J2
J3
J4
P2
4-20 mA +
4-20 mA –
SHIELD
COM
RS485 A
RS485 B
HIGH ALARM COM
HIGH ALARM NC
HIGH ALARM NO
AUX ALARM COM
AUX ALARM NC
AUX ALARM NO
LOW ALARM COM
LOW ALARM NC
LOW ALARM NO
FAULT COM
FAULT NC
FAULT NO
24 VDC –
24 VDC +
SHIELD
24 VDC –
24 VDC +
SHIELD
SHIELD
CALIBRATE
24 VDC –
4-20 mA
24 VDC +
P1-3
P1-2
P1-1
J2-3
J2-2
J2-1
J4-1
J4-2
J4-3
J4-4
J4-5
J4-6
J4-7
J4-8
J4-9
J4-10
J4-11
J4-12
J3-1 J3-2 J3-3 J3-4 J3-5
P2-6 P2-5 P2-4 P2-3 P2-2 P2-1
C706X Sensor Wired Directly to UD10
NOTE 1 GROUND THE SHIELD AT THE DISPLAY
UNIT END ONLY.
NOTE 2 HOUSINGS MUST BE ELECTRICALLY
CONNECTED TO EARTH GROUND.
SENSOR
TERMINATION
BOX
SEE NOTE 1
UD10 DISPLAY UNIT
C2423
RED
BLACK
* CONNECT THE GREEN
SENSOR LEAD TO THE
CHASSIS GROUND LUG
IN THE INSIDE BOTTOM
OF THE JUNCTION BOX.
C706X SENSOR
RED
BLK
+
+
G
G
–
–
GROUND LUG*
Sensor Connector
Power Supply Connector
Output Loop
Connector
MODBUS
Connector
Relay Connector
P1
J2
J3
J4
P2
4-20 mA +
4-20 mA –
SHIELD
COM
RS485 A
RS485 B
HIGH ALARM COM
HIGH ALARM NC
HIGH ALARM NO
AUX ALARM COM
AUX ALARM NC
AUX ALARM NO
LOW ALARM COM
LOW ALARM NC
LOW ALARM NO
FAULT COM
FAULT NC
FAULT NO
24 VDC –
24 VDC +
SHIELD
24 VDC –
24 VDC +
SHIELD
SHIELD
CALIBRATE
24 VDC –
4-20 mA
24 VDC +
P1-3
P1-2
P1-1
J2-3
J2-2
J2-1
J4-1
J4-2
J4-3
J4-4
J4-5
J4-6
J4-7
J4-8
J4-9
J4-10
J4-11
J4-12
J3-1 J3-2 J3-3 J3-4 J3-5
P2-6 P2-5 P2-4 P2-3 P2-2 P2-1
UD10 Wired to C706X Sensor with STB Termination Box
