Detecto 7550

0065-0647-0M Rev A  7550 FOLD-UP STATIONARY SCALE
8
Step 4 – Install the Scale on the Wall Mount
1. Once the Load Cell cable has been routed through the scale frame, remove the strap
securing the weighing platform to the scale frame. Refer to the note and picture in Step 1.
2. With an assistant, lift the scale above the wall mount and then lower it into position in the
channel of the wall mount.
3. Center the scale side to side in the channel of the wall mount.
Wall
Mount
Rubber
Bumper
Rubber
Bumper
