Deutz 914 - 3.1 Commissioning; 3.1.4 Bleed

3
© 2001
3.1 Commissioning Engine Operation
● Position collecting tank below the injection
pump.
● Unscrew ventilation valve 1 with screw-
driver.
● Move hand hump 2 in the direction of the
arrow until bubble-free fuel escapes from
the ventilation valve 1.
● Tighten ventilation valve 1, still pumping.
● Remove collecting tank and dispose of the
fuel in an environmentally-friendly manner.
3.1.4 Bleed
Model:
“Motorpal” model
© 35 212 0
