9
© 2001
Technical Specification 9.2 Torque Wrench Settings
Installation Pretension Retension Total Comments
[Nm] 1
st
position 2
nd
position 3
rd
position 4
th
position
Securing the alternator 20 180° – – – 180° M10 x 180
30 180° – – – 180° M14 x 230
Cylinder head cover – – – – – 12 ± 1,2 Nm –
Valve clearance adjusting screw – – – – – 22 ± 2 Nm –
Foot 30 60° 15° – – 75° M14 x 100
30 60° 45° – – 105° M14 x 110
30 60° 45° – – 105° M14 x 125
Intake manifold – – – – – 21 ± 2 Nm –
Exhaust manifold – – – – – 40 ± 4 Nm –
Oil drain screw – – – – – 150 ± 10 Nm M30 x 1,5
Oil drain screw – – – – – 80 ± 10 Nm M22 x 1,5
Injection valve attachment – – – – – 25–30 Nm –
