6
6.2 Fuel System Service and Maintenance
● Close the fuel shut-off valve.
● Screw out and remove filter cap 4.
● Catch any escaping fuel.
● Remove strainer 3 and clean with fuel.
● Remove seal ring 2.
● Clean filter casing 1 with fuel.
● Screw on filter cap 4 and strainer 3 with
new seal 2.
● Bleed fuel system (see 3.1.4).
● Open fuel shutoff valve.
● Check for leaks.
6.2.2 Fuel precleaning
Clean fuel filter
“Motorpal” model
Keep naked flames away when
working on the fuel system. Do
not smoke!
© 35 213 0
