DIGITAL AUDIO INPUT
Connector 1/4” (6,3mm) phone jack;
Shared with Left Analog input, software selectable
Type AES/EBU (IEC 60958)
Sample rate 32kHz, 44.1kHz and 48kHz
DIGITAL AUDIO OUTPUT
Connectors 1/4” (6,3mm) phone jack;
Shared with Left Analog output, software selectable
Type AES/EBU (IEC 60958)
Sample rate 48kHz
GPIO
Type 6 x GPI; 3.3V TTL logic with internal pull-up
6 x GPO; Open-collector; 20V/100mA
1 x RS-232
Connector DB-15
GPI Operating Modes Transparent two-way channel or Force Audio source trigger
GPO Operating Modes Transparent two-way channel or Source Audio loss indicator
RS-232 Operating Modes Transparent two-way channel or TCP/IP to RS-232 Redirector
RS-232 baud rate 9600 to 115200 bps
FRONT PANEL
Level Indicators 2 x 6 LED bar graphs
GPIO Indicators 2 x 6 LEDs
Status Indicators 4 LEDs
Headphones 1/8” (3.5mm) phones jack
SD Card microSD card slot up to 16GB
REMOTE CONTROL
Web interface Built-in web server with HTML5 interface
SNMP SNMP 2c
NETWORK
Connector RJ-45
Type 10/100Mbps Ethernet
Device Discovery UPnP Support
OPERATING CONDITIONS
Temperature 10°C - 45°C
Humidity < 75%, non-condensing
POWER
Voltage 12V DC, 1A
Power Consumption 10VA
Connector Power Jack 5.5mm
SIZE AND WEIGHT
Dimensions (W;H;D) 170 x 35 x 167 mm
Shipping Weight 270 x 54 x 230 mm / 0.9kg
HS Code 8517620000
