Basic Setup

ANALOG AUDIO INPUTS

Using a cable ending with two standard Phone jacks connect DB910 analog input the analog

audio outputs of your equipment.

WARNING: Do not exceed maximum input level. This may permanently damage the device.

DIGITAL AUDIO INPUT

Using a cable ending with a standard Phone jack connect DB910 AES/EBU input to the

AES/EBU audio output of your equipment.

ANALOG AUDIO OUTPUTS

Using a cable ending with two standard Phone jacks connect DB910 analog outputs to the

analog audio inputs of your equipment.

DIGITAL AUDIO OUTPUT

Using a cable ending with a standard Phone jack connect DB910 AES/EBU output to the

AES/EBU audio input of your equipment.

LAN PORT

For normal operation it is necessary the device to be connected to a local network or Internet

by cable with RJ-45 connector.
