5 Maintenance
Note!
The air cap can be replaced on the high-performance automatic spray gun AGMD
without removing it from the system.
For all other maintenance jobs, the high-performance automatic spray gun AGMD
must be removed from the intermediate plate and replaced by a new one.
5.1 Required tools and lubricants
The following are required for installation and removal:
 Workstation with vice and soft braces
 Hexagon socket head wrench, size 6
 Torque handle with socket wrench, size ½″
 Turnscrew
 AGMD-010 gun grease
Note!
Needle, needle set and piston should only be exposed to AGMD-010 grease.
Other grease can lead to a malfunction of the high-performance automatic spray
gun AGMD (unsuitable grease could cause swelling of needle set and piston).
5.2 Removing the high-performance automatic spray gun AGMD
Caution!
Danger of injury due to lines under pressure!
 When removing the high-performance automatic spray gun AGMD, spray
fluid may emerge under high pressure.
 Make certain no paint material gets into the air channels.
Rinse and blow out the material lines, then depressurise them.
Wear protective clothing and/or glasses.
Note!
Prior to the installation of the new high-performance automatic spray gun AGMD,
make sure that the O-rings are in place and that they are lubricated.
1. Loosen the fixing screw if there is one.
2. Push the unlocking pin on the intermediate plate.
3. Turn the high-performance automatic spray gun AGMD 45° anti-clockwise and
remove.
