High-performance automatic gun
AGMD
1-1-AGMD-514&515-E-002-1
32
7.2.2 Parts list
Item
Part no.
Description
Qty.
1
MBC-368
AGMD-368
Retaining ring
Retaining ring with seal (optional)
1
2
See 7.2.3
Air cap
1
3
See 7.2.3
Nozzle
1
4
AGMD-65-1
Gasket
2
5
AGMD-34
Air distributing ring with lock
1
6
AGMD-195
AGMD-195-U
Head
Head with circulation (for gun with
circulation features)
1
7
AGMD-244
Locking device
1
7.1
AGMD-044-3
Centring screw (optional)
7.2
AGMD-244-8
Locking device for intermediate plate
AGMD-245-8 (option)
8
AGMD-130
Fillister head screw for AGMD-244
1
9
AGMD-405-1
Needle set
1
10
See 7.2.3
Paint needle
1
11
SS-2393
O-ring
2
12
AGMD-93-K5
O-rings (pack of 5)
1
13
AGMD-217
Head holder
1
14
AGMD-243-1
Piston
1
15
AGMD-219
Spring pin
1
16
AGMD-110
Compression spring
1
17
AGMD-111
Compression spring
1
18
AGMD-116
Set screw with slot
1
19
AGMD-115
Elastic pressure piece
1
20
AGMD-242
End plate
1
21
AGMD-131
Hexagon screw
4
7.2.3 Nozzle and needle combination, air caps
Air cap
Nozzles
Paint needle
AV-4920-…/
AGMD-420-...
AGMD-46c
HVLP
FF / 1.4 mm
FZ
AGMD-46c
HVLP
FX / 1.1 mm
FX
AGMD-407-122c
Trans Tech
FF / 1.4 mm
FZ
AGMD-407-122c
Trans Tech
FX / 1.1 mm
FX
AGMD-123
Trans Tech
FF / 1.4 mm
FZ
Air caps marked ″C″ are certified.
Nozzles and needles are made of stainless steel.
