7.3 Spare parts for special applications
7.3.1 AGMD-243 piston (hard anodised aluminium)
As an alternative to piston AGMD-243-1
(item 14), the piston made of hard
anodised aluminium can also be used.
Instead of the two lip seals, it has O-rings
AGMD-120 and AGMD-121.
Both O-rings must be lubricated with gun
grease AGMD-010.
7.3.2 AGMD-405-H and AGMD-405-H-C (needle set)
As an alternative to needle set AGMD-
405-1 (item 9), the needle set AGMD-405-
H is used for UV-hardening coatings.
The needle set is set into the gun head,
using the setscrew AGGS-32-K5.
The needle set is also available in certified
design AGMD-405-H-C.
