DeVilbiss AGMD Series - Page 17

High-performance automatic gun
AGMD
1-1-AGMD-514&515-E-002-1
16
4. Loosen the four hexagon screws
(item 21).
5. Remove the end plate (item 20).
6. Pull off the head holder (item 13) towards
the back away from the head.
7. Remove the two springs (items
16 and 17), spring pin (item 15) and paint
needle (item 10).
