DeVilbiss DV5HH - Filter Specifications; Pressure Accuracy and Flow Rate; Additional Device Specifications

EN - 14 SE-DV54-1
Filter Specifications
Standard Filter ......................................................................................................................................... > 3.0 micron particles
Optional Fine Particle Filter ..................................................................................................................... > 0.3 micron particles
Dynamic Short-Term Pressure Accuracy with and without DV5HH Humidifier (Per
ISO 17510-1:2007)
Waveform Volume[mL] BreathRate[min-1]
SetPressure
[cmH
2
O]
PressureAccuracy
[Pk-PkcmH
2
O]
Sinusoidal
cycle with I:E =
1:1
500 10, 15, 20
3.0 0.5
7,0 0.5
12,0 1.0
16,0 1.0
20,0 1.0
Maximum Flow-Rate (per ISO 17510-1:2007)
TestPressures
3,0cmH
2
O 7,0cmH
2
O 12,0cmH
2
O 16,0cmH
2
O 20,0cmH
2
O
Measured pressure at the patient
connection port (cmH
2
O)
2.9 6.4 11.0 15.0 19.0
Averageowatthepatientconnectionport
(l/min)
83.8 126.8 137.4 130.0 113.8
Long Term Static Pressure Accuracy ................................................................................................................. +/- 0.5 cmH
2
O
Additional Specifications
Equipment classification with respect to protection from electric shock ........................................................................ Class II
Degree of protection from electric shock ................................................................................................. Type BF Applied Part
Degree of protection against ingress of liquids ...................................................................................... IPXI Drip-proof vertical
Mode of operation .................................................................................................................................................... Continuous
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide
