DeVilbiss SRI PRO series - Parts List; Service Parts

Page 6 SB-2-855-B
PARTS LIST
REF.
NO.
DESCRIPTION PART NO. QTY.
1 Air Cap Retaining Ring 1
2 Slip Ring 1
3 Air Cap 1
5 Retaining Ring Seal SRI-35-K5 1
6 Air Cap & Ring See chart 1, p13 1
8 Fluid Nozzle See chart 2, p13 1
9 Separator SRIPRO-2-K5 1
12* Body Bushing Seal 1
13 Body Bushing 1
14 Body Bushing & Seal 702728 1
15 Fluid Needle See chart 2, p13 1
16* Needle Spring 1
17* Needle Spring Pad 1
18 Fluid Adjusting Knob 1
19
Fluid Adjusting Knob,
Spring & Pad Kit
PRO-3-K 1
20* Retaining Clip 1
21 Spreader Valve Body 1
22* Spreader Valve Seal 2
23
Spreader Valve Adjusting
Knob
1
24* Valve Pin 1
25 Spreader Valve Assembly SRIPRO-401-K 1
26* Needle Packing 1
27* Packing Spring 1
28 Packing Nut 1
29
Packing, Spring &
Packing Nut Kit
702731 1
30 Air Valve Body 1
31 Air Valve Cage 1
REF.
NO.
DESCRIPTION PART NO. QTY.
32 Air Valve Poppet 1
33 Air Valve Spring 1
34 Air Valve Spring Pad 1
35 Air Valve Seal SN-34-K5 1
36 Air Valve Assembly 702732 1
37*
Trigger Stud Screw
(T20 Star)
1
38 Trigger 1
39* Trigger Stud 1
40 Trigger, Stud & Screw Kit SN-42-K 1
41 Air Inlet SN-40-K 1
42
Color ID Ring Kit
(4 colors)
702735 1
43 Airflow Valve PRO-404-K 1
44 Circlip 1
45 Wrench (kit of 2) SRI-50-K2 1
46
Air Valve Service Tool
(included in 702732)
1
47 Air Flow Valve Knob 1
SERVICE PARTS
Spray Gun Repair Kit
(includes items marked *)
702736
Seal & Pin Kit, kit of 5
(items 20, 22 and 24)
GTI-428-K5
For accessories, see page 16
