Introduction 13
devolo dLAN 200 AVpro Wireless N
This example involves three port-based VLANs (colour-
coded):
쎲 VLAN group one (PCs 1, 7, 8, 9) e.g. at Ethernet
port two
쎲 VLAN group two (PCs 2, 10, 11, 12) e.g. at Ether-
net port one
쎲 VLAN group three (PCs 3, 4, 5, 6) e.g. at Ethernet
port three
쎲 One WLAN is assigned to each VLAN group.
The configuration of the networking example can have
the following appearance:
햲 Under VLAN configuration enable the VLAN
function and create the desired VLANs with a cor-
responding VLAN ID.
