Devolo Magic 1 LAN 1-1 - Reading the indicator light

15 Introduction
devolo Magic 1 LAN
1-1
2.3.1Reading the indicator light
The integrated indicator light (LED) shows the sta-
tus for the devolo Magic 1 LAN
1-1
by illuminating
and/or flashing:
LED Flashing be-
haviour
Meaning LED status display
(web interface*)
1 Red LED Lights up for
up to 2 sec.
Start-up process Cannot be disabled
2 Red LED Flashes at in-
tervals of 0.5
sec. (on/off)
Status 1:
The reset of the devolo Magic adapter was
successful. The PLC/reset button has been
pressed and held for 10 seconds.
Status 2:
The devolo Magic adapter (once again) has
the factory default settings. Since the last re-
set, no pairing with another devolo Magic
adapter has taken place.
Connect the adapter with another
devolo Magic adapter to create a full-
fledged PLC network as described in Chap-
ter 2.3 Pairing.
Cannot be disabled
