Devolo Magic 1 LAN 1-1 User Manual

Appendix 34
devolo Magic 1 LAN
1-1
5 Appendix
5.1 Technical specifications
5.2 Bandwidth optimization
To significantly improve the transmission capacity
of the network, we recommend that you comply
with the following "connection rules":
b Plug the devolo Magic 1 LAN
1-1
directly into a
wall socket. Avoid using power strips. This may
impair the transmission of the PLC signals.
b If there are several sockets in the wall directly
next to each other, they behave like a power
strip. Individual sockets are optimal.
Security 128 Bit AES
Device port 1x RJ45
(Gigabit Ethernet port)
Power consumption Maximum: 3.2 W
Typical: 2.8 W
Stand-by: 0.5 W
Power supply internal
196-250 V AC
50 Hz
Temperature
(Storage/Operating
-25°C to 70 °C / 0°C to
40°C
Dimensions (in mm,
without plug)
133x66x42 (HxWxD)
Ambient conditions 10-90% Humidity,
non-condensing
Certifications CE
Fig. 9: Bandwith optimization

Devolo Magic 1 LAN 1-1 Specifications

General

Product Type	Powerline adapter
Data Transfer Rate	1200 Mbps
Connectivity Technology	Wired
Interface	Ethernet
Ethernet Ports	1
Maximum Data Rate	1200 Mbps
Frequency Range	2-68 MHz
Encryption	128-bit AES
Data Link Protocol	Ethernet, Fast Ethernet
Plug Type	EU
Operating Temperature	0 °C to 40 °C
