Network configuration 34
devolo Magic 2 WiFi next
The Wi-Fi network mode field lets you define your
preferred setting by clicking the respective field:
b 2.4 GHz + 5 GHz – Both frequency bands are
used
b 2.4 GHz – Only the 2.4 GHz frequency band is
used
b 5 GHz – Only the 5 GHz frequency band is used
b Off – If desired, you can completely switch off
the Wi-Fi section of your
devolo Magic 2 WiFi next here.
Keep in mind that after saving this set-
ting, you will be disconnected from any
existing wireless connection to the
devolo Magic 2 WiFi next. In this case,
configure the device over Ethernet.
Network name
The network name (SSID) determines the name of
your wireless network. You can see this name
when logging onto the Wi-Fi, allowing you to
identify the correct Wi-Fi network.
Channels
There are 13 channels available in the 2.4 GHz
frequency band. The channels recommended for
Europe are channels 1, 6 and 11. This ensures the
frequency bands of the channels do not overlap
and any connection problems are avoided.
There are 19 channels available in the 5 GHz
frequency band.
The channel selection default setting is
Automatic.
The devolo Magic 2 WiFi next regularly and
automatically executes the channel selection in
this setting. In other words, if the last connected
station logs out, a search for a suitable channel is
carried out immediately. If no stations are
connected, the device automatically selects a
channel every 15 minutes.
It is worth noting that connected devices also have
to support the increased frequency band of 5 GHz.
From channel 52 onward you go into the radar
range. When accessing the device for the first time,
a radar detection phase (DFS) starts automatically,
during which time the devolo Magic 2 WiFi next
cannot be accessed via Wi-Fi. This can take up to 10
minutes.
In the Channel field, you can manually select a 2.4
GHz and a 5 GHz channel. If you are not sure which
wireless channels are used by nearby devices,
select the Automatic option.

Devolo Magic 2 WiFi next Specifications

General

MIMO type	Multi User MIMO
Power plug	-
Ethernet LAN	Yes
Damping filter	2 - 86 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA, WPA2, WPA3-PSK, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	2400 Mbit/s
Maximum operating distance	500 m
Ethernet LAN interface type	Gigabit Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
WLAN data transfer rates supported	300, 867 Mbit/s
Mobile operating systems supported	Android, iOS
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Antenna type	Internal
Certification	WEEE
Product color	White
Country of origin	Germany
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power over Ethernet (PoE)	No
Power consumption (standby)	3.1 W
Power consumption (typical)	8.9 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	40 mm
Width	76 mm
Height	152 mm
Package depth	92 mm
Package width	118 mm
Package height	190 mm
Package weight	570 g
