Network configuration 40
devolo Magic 2 WiFi next
Setting the time quota
Under Time Quota, the time limit can be selected.
Confirm your settings by clicking the Disk icon.
Setting the time period
Under Time Period, the desired time period can be
selected. After entering the interval, enter the
desired start and end times in hour and minute
format.
Confirm your settings by clicking the Disk icon.
If you want to delete a time quota (time limit) or a
time period from the list, click/touch the dustbin
icon.
4.4.7Wi-Fi Protected Setup (WPS)
Wi-Fi Protected Setup (WPS) is one of the interna-
tional encryption standards developed by the Wi-Fi
Alliance for easily and quickly setting up a secure
wireless network. The encryption keys of the re-
spective Wi-Fi devices are transmitted automatical-
ly and continuously to the other Wi-Fi device(s) in
the wireless network.
Enabling WPS encryption
In order to be able to use WPS encryption, activate
the Enable option.
The devolo Magic 2 WiFi next offers two different
variants for transmitting these encryption keys:
WPS using WPS pushbutton
1 Start the encryption process on the
devolo Magic 2 WiFi next
a By pressing the Wi-Fi button on the front
side of the device or
a By pressing the corresponding Start button
on the user interface under Wi-Fi  WPS
Pushbutton.
2 Then either press the WPS key of the Wi-Fi
device you are adding or enable the WPS
mechanism in the Wi-Fi settings of the Wi-Fi
device. Now the devices exchange their encryp-
tion keys and establish a secure Wi-Fi connec-

Devolo Magic 2 WiFi next Specifications

General

MIMO type	Multi User MIMO
Power plug	-
Ethernet LAN	Yes
Damping filter	2 - 86 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA, WPA2, WPA3-PSK, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	2400 Mbit/s
Maximum operating distance	500 m
Ethernet LAN interface type	Gigabit Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
WLAN data transfer rates supported	300, 867 Mbit/s
Mobile operating systems supported	Android, iOS
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Antenna type	Internal
Certification	WEEE
Product color	White
Country of origin	Germany
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power over Ethernet (PoE)	No
Power consumption (standby)	3.1 W
Power consumption (typical)	8.9 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	40 mm
Width	76 mm
Height	152 mm
Package depth	92 mm
Package width	118 mm
Package height	190 mm
Package weight	570 g
