Carton Contents
1 Rolling miter saw/planer stand
1 Leg extension (E)
2 Work support arms (1 with black cap) (B)
Carton 1:
2 Wheels (D)
1 Handle (I)
1 Storage foot (C)
Carton 2:
2 Extension work support assemblies (H)
2 Wheel/storage foot connectors [left (L) and right (R)] (N)
Hardware bag 1:
2 Cord wrap brackets (left and right) (X)
2 M8 washers (JJ)
2 M8 nuts (KK)
Hardware bag 2:
2 Axles (P)
2 Bushings (U)
4 Washers (Q)
2 Nuts (R)
Hardware bag 3:
6 M8 x 15 mm button head screws (L)
6 Curved washers (M)
1 M6 x 10 mm button head screw (T)
1 M6 lock washer (Y)
1 M8 x 20 mm button head screw with thread locking patch (S)
1 M8 lock washer (Z)
Tools Required
• Hex wrench (J) (supplied)
• Adjustable wrench
• 1/2 inch open end wrench
• 3/4 inch open end wrench
• Wire cutting pliers
UNPACKING AND CLEANING
Carefully unpack the product and all loose items from the shipping
container(s). Remove the rust-preventative oil from unpainted surfaces
using a soft cloth moistened with mineral spirits, paint thinner or
denatured alcohol.
NOTICE: Do not use highly volatile solvents such as gasoline,
naphtha, acetone or lacquer thinner for cleaning your stand.
Components (Fig. 1)
WARNING: Never modify the stand or any part of it. Damage or
personal injury could result.
Refer to Figure 1 for Components List.
ASSEMBLY
WARNING: PINCH AND IMPACT HAZARD. The spring loaded
mechanism is under tension and can open unexpectedly, with high
force. To reduce the risk of serious personal injury, do not raise or
lower stand until the assembly is complete. Do not cut the large
securing cable ties (W, Fig. 2) until instructed to do so later in the
manual.
WRENCH STORAGE (FIG. 3)
The supplied hex wrench (J) comes in the wrench storage location in
the corner of the stand.
