Dewetron DEWE-5000 - Page 24

24
Main System
Internal battery power supply: option DEWE-5000-PS-BAT
320 W DC power supply
with XP-04 battery management
Input:
Input range:
Input frequency:
Max. input current:
18 to 24 V
DC
(nom. 18 V
DC
)
DC
12 A
External AC power supply: 90 to 260 V
AC
(DEWE-POW-24-350 included as standard accessory)
Output:
Output power:
Output voltages:
320 W with XP-04 battery management (with DCDC-123)
+3.3 V (max. 10 A)
+5 V (max. 10 A)
+12 V (max. 12 A)
Power supply pin assignment:
+-
Connector type
2-pin. male
LEMO EGJ.2B.302
Note: If the system is powered by batteries, please take care that there are at least 2 batteries installed!
In some special applications 3 batteries are necessary! (Hot swap of the batteries not possible)
External AC/DC power supply (standard accessory included with option 5000-PS-BAT)
AC/DC power supply DEWE-POW-24-350
Input:
Input voltage:
Input frequency:
Input current (typ.):
Inrush current (typ.):
Leakage current:
P.F.C. (typ.):
90 to 264 V
AC
/ 127 to 370 V
DC
universal input
47 to 63 Hz
2 A @ 230 V
AC
/ 4 A @ 115 V
AC
44 A @ 230 V
AC
/ 22 A @ 115 V
AC
<2 mA @ 240 V
AC
0.95 @ 230 V
AC
/ 0.98 @ 115 V
AC
Output:
Output voltage:
Min. load:
Rated load (free / fan):
Output tolerance:
Ripple & Noise (max.):
Ef ciency (typ.):
Output connector:
24 V
0 A
12.5 A / 14.6 A
±2 %
150 mV
88 %
Banana jacks and LEMO EGG.2B.302
Protection:
Overload:
Over voltage:
Over temperature:
Short curcuit:
105 % to 130 % constant current limiting, auto recovery
26.7 to 32.4 V; Hiccup mode, auto recovery after fault has been removed
> 80°C ±5°C detect on heat sink of power transistor Shutdown, auto recovery after temp. has fallen
Yes
Setup time: <2000ms @ 230V
AC
/ 4000ms @ 115V
AC
Rise time: <100ms @ 230 V
AC
/ 100ms @ 115 V
AC
Holdup time: 16ms @ 230 V
AC
/ 16ms @ 115 V
AC
Withstand voltage: I/P-O/P:3 KV
AC
, I/P-FG:1.5 KV
AC
, O/P-FG:0.5 KV
AC
/ 1 minute
Isolation resistance: I/P-O/P, I/P-FG, O/P-FG: 500 V
DC
/ 100 MOhm
Switching frequency: 100 kHz
Temperature:
Operating:
Derating:
Storage:
-10 to 65°C
45 to 60°C: 2 %/°C (3.5 & 5 V: 40 to 65°C: 2 %/°C)
-40 to 85°C
Humidity:
Operating:
Storage:
20 to 90 % RH
10 to 95 % RH (non condensing)
M.T.B.F.: > 106 K hours ( according to MIL-HDBK-217F at 25°C environment)
Safety: Approved: UL 60950-1 / TÜV EN60950-1
EMC:
EMI
EMS
EN55022 Class B / EN61000-3-2,3
EN61000-4-2,3,4,5,6,8,11 / ENV50204
Dimensions (W x D x H): 248 x 106 x 62 mm (9.8 x 4.2 x 2.4 in.)
Weight: 1.7 kg (3.7 lbs)
If option 5000-PS-BAT is installed, there are 3 slots for hot-
swappable smart batteries available in the system. Standard
shipment includes 2 smart batteries, more can be ordered
additionally (option BAT-95WH).
Optional cables:
C7502: LEMO 2B jack to LEMO 2B plug, 2 m. (used for connecting
DEWE-2600 to DEWE-POW-24-350 or to DEWE-DCDC-
24-350-ISO)
C8502: LEMO 2B jack to banana plugs, 2 m.
