DE-M040302E • DEWE-5000 • Technical Reference Manual • Printing version 2.2.3 • January 19, 2012
Main System
DEWE-5000 with option PS-BAT and external AC/DC power supply
Smart battery packs
Smart battery packs are equipped with an integrated
circuit which stores information (such as manufacturer,
serial number, production date etc.) and monitors the
current battery status in terms of discharge rate, predicted
remaining capacity, temperature, voltage etc. The battery
packs, supplied with every battery powered DEWETRON
system, are even capable of displaying their charge state
without a separate device. With the push of a button,
a LED display on the battery pack shows the current
charge state in 25% steps. An intelligent battery controller,
integrated in our DEWETRON systems, takes care of
the charging and discharging process in order to ensure
maximum battery performance and life time.
2
4
V
D
C
DEWE-POW-24-350
90 to 260 VAC IN
External AC Power supply
Lemo EGG.2B.302
Cable C7502
To Next Page
