External battery charger (optional)
External battery chargerCH5000A/E/U
Power supply:
Input voltage: 90 to 260 VAC, 24V
Input current:2.5 A
Mains Cord:CH5000E - 220 V European 2-pin connector with ground recess
Dimensions (WxDxH): 180 mm x 92 mm x 58 mm
Weight:ca. 250 g
Mating connector: 5-blade standard battery connector
From time to time, due to the aging process of the batteries, it is necessary to recalibrate the battery in order
to retain the accuracy and reliability of the fuel gauge. This can be archieved with an external battery charger
(BAT-CHARGER) which is optionally available. Another advantage of the BAT-CHARGER is that additional
batteries can be recharged without being in the measurement unit. This allows the measurement unit to run
non-stop without being connected to the power net, thanks to the hot-swap capability of the battery packs.
