Dexter Laundry B Series - Page 5

8514-265-001 REV C PAGE 5
SPECIFICATIONS
30 lb. Industrial Stack Dryer: T-30X2
DN30X2E_-(71/74/77/78)EB_X
Cabinet Height 76 1/4” 1937 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 31 1/2” 800 mm.
Cabinet Depth 49 1/2” 1257 mm.
Floor to Bottom of Door- Bottom Dryer 7 5/8” 194 mm.
Floor to Bottom of Door- Top Dryer 45 1/4” 1149 mm.
Door Opening 22 5/8” 575 mm.
Dry Wt. Capacity 30 x 2 lbs. 13.6 x 2 kg.
Cylinder Diameter 30” 762 mm.
Cylinder Depth 27 1/2” 699 mm.
Cylinder Volume 11.25 cu. ft. 319 liters
Lint Screen Area 453 sq. in. 2923 sq. cm.
Exhaust Size 8” 203 mm.
Make-up Air 1.5 sq. ft. 1394 sq. cm.
Example: 1.5 sq. ft = 1 ft. long X 1.5 ft. wide
Motor Size 1/2 H.P. .373 kW
Airflow (60 hz) 600 CFM 17.0 m^3/min
Electrical Specifications – Model -71
Voltage/Hz/Phase 208V/60Hz/3Phase/24kW Heat
Running Amps 85
Minimum Dual Element Time Delay Fuse 90 Amp
Wire Size #2
Electrical Service 4 wire + ground
Electrical Specifications – Model -74
Voltage/Hz/Phase 240V/60Hz/3Phase/24kW Heat
Running Amps 75
Minimum Dual Element Time Delay Fuse 80 Amp
Wire Size #3
Electrical Service 4 wire + ground
Electrical Specifications – Model -77
Voltage/Hz/Phase 120&208V/60Hz/1Phase/20kW Heat
Running Amps 120
Minimum Dual Element Time Delay Fuse 125 Amp
Wire Size (1/0)
Electrical Service 3 wire + ground
Electrical Specifications – Model -78
Voltage/Hz/Phase 120&240V/60Hz/1Phase/20kW Heat
Running Amps 105
Minimum Dual Element Time Delay Fuse 110 Amp
Wire Size (1/0)
Electrical Service 3 wire + ground
Shipping Weight 750 lbs. 340 kg.
Net Weight 699 lbs. 317 kg.
Clearance Behind Machines (min.) 18” 457 mm.
