8514-238-001 REV PR page 23
No hot water
in detergent
dispenser
Check coil continuity at terminals and replace if no
continuity. 120 V power only on for 20 second in wash
bath.
Check water inlet screens for blockage and clean screens
if necessary.
Check to insure that water is turned on and operating.
Check black & white wire harness.
Hot water
does not
enter tub in
wash
Check coil continuity at terminals and replace if no
continuity. Check for 120 V power from main relay PCB.
Check water inlet screens for blockage and clean if
necessary.
Check to insure that water is turned on and operating.
Blk or Wht wire at
main controller
Check black or white wires at Molex plug on PCB at main
controller and at relay PCB.
Check pressure switch continuity between terminals. If
no continuity, check pressure switch hose for obstruction.
If hose okay, change pressure switch.
No cold water
to tub in
wash
Check coil continuity at terminals and replace if no
continuity.
Check water inlet screens for blockage and clean if
necessary.
Check to insure that water is turned on and operating.
Blk or whit wire
at controller and
main relay PCB
Check black or white wires at Molex plug on PCB at main
controller and at relay PCB.
Check pressure switch continuity between terminal
contacts. If no continuity, check pressure switch hose for
obstruction. If hose okay, change pressure switch.
Water comes
in but level
does not rise
Check these areas:
• Drain valve blockage
• Drain valve motor and gear train. If power but drain
valve does not close, replace valve.
• Power to the drain valve. If no power to drain valve,
check (brn/yel) circuit for power.
Blk or whit wire
at controller
Check black and white wires at molex plug on main PCB
controller and at main relay PCB
Water does
not flush
softener
compartment
Check coil continuity at terminals and replace if no
continuity.
Check water inlet screens for blockage and clean if
necessary.
Check to ensure that water is turned on and operating.
Water does
not flush
softener
compartment
Check pressure switch continuity between terminals. If
no continuity, check pressure switch hose for obstruction.
If hose okay, change pressure switch.
Check for blockage in pressure switch hose. Check for
pressure switch opening circuit across terminals. Replace
switch if contacts do not open.
Check hoses and drain valve for blockage. Check if
inadequate size. If necessary check building drains for
blockage.
