8514-296-001 REV K page 83
DELAY Communication
loss
Condition This is an intermediate error code that
displays as the control is attempting to re-
establish communications with the
variable frequency drive. It is a condition
of other specified Error Codes (for
example Comm Error6).
Delay
4 cycles of 10 seconds if during tumble
portion of cycle
4 cycles of 2 minutes if during spin
portion of cycle
Action Prompt is displayed during each of the
specified 10 second or 2 minute periods.
Error condition (such as Comm Error4)
occurs, but Delay is shown instead of
specific Error Code. Action during this
time is dependent on the specific error
code that caused it.
Solution
None. Either communication is re-
established or the specific Error Code
eventually occurs.
DRIVE STO
VFD Safety
Torque Off Error
Condition
This error occurs when the drive detects
an open circuit in both the S1 and S2 to
+24V drive jumper connections.
Delay Occurs following the “DELAY” error (see
corresponding detail)
Action
Stop the machine and clear the cycle.
Keep the door locked until the machine
has stopped moving and then unlock the
door.
Solution Check VFD light code before turning off
power. Turn the power off to the washer.
Check the wiring connections to the S1,
S2, and +24V drive jumper connections.
If no problem is observed, turn on power
to the washer and test. If problem
reappears, contact your Dexter
representative.
DRIVE STL VFD Internal
Hardware Error
Condition This error occurs when the drive detects
an open circuit in either the S1/+24V or
S2/+24 drive jumper connections.
Delay Occurs following the “DELAY” error (see
corresponding detail)
Action
Stop the machine and clear the cycle.
Keep the door locked until the machine
has stopped moving and then unlock the
door.
