Control Panel Part # by Model
Key Description T900 T1200 QTY
1 Panel Control Assembly(panel only) 9989-560-001 9989-560-001 1
* Screw, to Side Panels 5/16, Hxwshrhdundct #10Bx
1/2”
9545-008-026 9545-008-026 4
2 Plate-Latch, Top 9452-625-001 9452-625-001 2
3 Nut, #8-32 8640-412-005 8640-412-005 4
4 Locator Panel 9355-001-001 9355-001-001 1
5 Screw FillHDCR 10Bx1/2” Guide 9545-008-023 9545-008-023 1
6 Spacer Pushbutton (Micro) 9538-178-001 9538-178-001 1
7 Pushbutton Control (coin)[Blue] 9035-060-003 9035-060-003 1
7 Pushbutton Control (coin)[Black] 9035-060-005 9035-060-005 1
8 Retainer Pushbutton (Micro) 9486-158- 001 9486 -158- 001 1
9 Nut Hexelasticstop #4-40 8640-424-002 8640-424-002 2
10 Spacer Plastic #6x9/16 9538-157-018 9538-157-018 5
11 PCB assembly Control /Display STOP 9473-010-001 9473-010-001 1
12 Nut Elasticstop #6-32 8640-411-002 8640-411-002 4
13 Nut-Hexkeps, #6-32 8640-411-003 8640-411-003 1
14 Harness LEDPCB 9627-797-001 9627-797-001 1
* Harness Doorlock, Switches 9627-791- 005 9627-791-005 1
15 Spacer Plastic #6x9/16 9538-157-018 9538-157-018 2
16 PCB assembly Mode lights 9473-005-001 9473-005-001 1
17 Nut Hexkeps #6-32 8640-411-003 8640-411-003 2
18 Accecptor-Coin, Optical 9021-041-001 9021-041-001 1
19 Retainer, Coin Accecptor 9486-149-001 9486-149-001 2
20 Screws, Torx, T-10, 4Bx5/8ss 9545-053-002 9545-053-002 4
21 Switch Assembly Emergency Stop (includes wire
harness)
9732-223-001 9732-223-001 1
22 Spacer Plastic #8x5/16 E-Stop 9538-157-020 9538-157-020 2
23 Plate to mount e-stop button 9452-725-001 9452-725-001 1
24 Nuts-Hexkeps, #8-32 8640-412-005 8640-412-005 3
25 Plastic Shield over main PCB 9550-184-001 9550-184-001 1
26 Nuts-Hexkeps, #8-32 8640-412-005 8640-412-005 3
27 Nameplate,Control Panel (Blue) 9412-206-002 9412-214-002 1
27 Nameplate,Control Panel (Black) 9412-206-001 9412-214-001 1
28 Motor Ass’y, Door Locking (see Door Lock Group for
parts breakdown)
9892-015-001 9892-015-001 1
29 Nuts-Hexkeps, #8-32 8640-412-005 8640-412-005 4
* Battery 8612-001-001 8612-001-001 1
30 Cable, USB 9806-022-001 9806-022-001 1
31 Screw-Torx T10, #4-40x3/8ss 9545-020-004 9545-020-004 2
32 Nut, Spring 8640-399-008 8640-399-008 2
124
Part # 8533-081-001 1/18
