T900 C-Series Washer (208-240 only)
Resistance
Motor Winding Wire # Minimum Maximum
T900 1ph or 3ph 60hz Main (wash & spin) T1 & T2 2.4 2.8
Dexter #9376-308-001 T2 & T3 2.4 2.8
Marathon # T1 & T3 2.4 2.8
T1200 C-Series Washer
Resistance
Motor Winding Wire # Minimum Maximum
T1200 1ph or 3ph 60hz Main (wash & spin) T1 & T2 .944 1.097
Dexter #9376-329-001 T2 & T3 .944 1.097
Marathon # T1 & T3 .944 1.097
NOTE: Resistance values are measured at the stator. Values at the end of the motor wiring
harness may be slightly higher.
Vended Drive Motor Inverter Type
Motor-Winding Resistance Chart
66
Part # 8533-081-001 1/18
