Dexter Laundry T900 - Bolt Torque Chart

T-900, T-950 & T-1200 Bolt Torque Chart
Bolt Size Where Used Torque
7/16” Stainless Cap Screw Outer Tub to Bearing Housing 60-80 ft/lbs
3/4” Bolt Bearing Housing to Frame 200-300 ft/lbs
1/2” Bolt Outer Tub Clamping Band to Frame 70 -110 ft/lbs
1/2” Bolt Outer Tub Clamping Band - Top 30-40 ft/lbs
3/8” Cap Bolt Driven Pulley to Hub 28-32 ft/lbs
80
Part # 8533-081-001 1/18
