Dexter Laundry WN0675 - T-675 Bolt Torque Chart

T-675 Bolt Torque Chart
Bolt Part Number Bolt Size Where Used Torque Qty.
9545-017-013 1/2-13 x 2” Tub Feet to Base 70-110 ft-lb 2
9545-029-009 3/8-16 x 3” Front Clamp Ring Ends 100-120 in-lb 1
9545-059-004 7/16-14 x 1” Bearing Housing to Tub Back 60-80 ft-lb 6
9545-057-002 3/4-10 x 3” Bearing Housing to Base 200-300 ft-lb 6
9545-060-004 5/8-11 x 2” End of Shaft 100-125 ft-lb 1
9545-029-011 3/8-16 x 2“ Drum Pulley Bushing 28-32 ft-lb 3
9545-018-024 1/4-20 x 1” Motor Pulley Screws 80-90 in-lb 3
8640 -413-006 #10-32 Soap Box Nuts 10-20 in-lb 6
T-975 Bolt Torque Chart
Bolt Part Number Bolt Size Where Used Torque Qty.
9545-017-013 1/2-13 x 2” Tub Feet to Base 70-110 ft-lb 2
9545-029-009 3/8-16 x 3” Front Clamp Ring Ends 100-120 in-lb 1
9545-059-004 7/16-14 x 1” Bearing Housing to Tub Back 60-80 ft-lb 6
9545-057-002 3/4-10 x 3” Bearing Housing to Base 200-300 ft-lb 6
9545-060-001 5/8-11 x 1.5” End of Shaft 100-125 ft-lb 1
9545-029-011 3/8-16 x 2“ Drum Pulley Bushing 28-32 ft-lb 3
9545-018-024 1/4-20 x 1” Motor Pulley Screws 80-90 in-lb 3
8640 -413-006 #10-32 Soap Box Nuts 10-20 in-lb 6
T-1475 Bolt Torque Chart
Bolt Part Number Bolt Size Where Used Torque Qty.
9545-017-013 1/2-13 x 2” Tub Feet to Base 70-110 ft-lb 2
9545-029-009 3/8-16 x 3” Front Clamp Ring Ends 100-120 in-lb 1
9545-059-004 7/16-14 x 1” Bearing Housing to Tub Back 60-80 ft-lb 6
9545-066-001 7/8-9 x 3.5” Bearing Housing to Base 600-650 ft-lb 6
9545-057-004 3/4-10 x 1.5” End of Shaft 100-130 ft-lb 1
9545-029-011 3/8-16 x 2“ Drum Pulley Bushing 28-32 ft-lb 3
9545-018-024 1/4-20 x 1” Motor Pulley Screws 80-90 in-lb 3
8640 -413-006 #10-32 Soap Box Nuts 10-20 in-lb 4
67
Part # 8533-126-001 11/21
