8
ASSEMBLY AND PARTS LIST
OPTION 3- VIDEO (For all Standard Televisions)
4. Connect the yellow video lead and AUDIO L/R (red and white lead) out
connectors on the STB to the AV in on the back of the TV. Optional: Connect
Optical S/PDIF out connector on the STB to the Audio-Amplifier using optical
cable.
Note: Please ensure that your TV is set to the correct input channel depending
on your connection type ex;AV1, AV2, Component , Scart1 ,HDMI or an input
selection button on the TV remote control where you can select the above.
Check TV user guide/ Support line if unable to select an input.
