DH Instruments RPM4 User Manual

1. INTRODUCTION
Page 3 © 2004-2007 DH Instruments, a Fluke Company
Q-RPTs of A10M and lower are available with two different performance
levels, STANDARD class and PREMIUM class. See the product label on the
RPM4 rear panel, the Q-RPT module label on the rear panel and/or the
product calibration reports to determine the class of the Q-RPT(s) installed
in RPM4.
Table 1. Reference Pressure Transducer (Q-RPT) Module Designations and Ranges
SI VERSION US VERSION
Q-RPT
DESIGNATION
MAXIMUM
RANGE
[kPa]
Absolute
MAXIMUM
RANGE
[kPa]
Gauge
MAXIMUM
RANGE
[psi]
Absolute
MAXIMUM
RANGE
[psi]
Gauge
A280M-L
1
280 000 280 000 40 000 40 000
A200M-L
1
200 000 200 000 30 000 30 000
A140M-L
1
140 000 140 000 20 000 20 000
A100M-L
1
100 000 100 000 15 000 15 000
A70M
1
70 000 70 000 10 000 10 000
A40M
1
40 000 40 000 6 000 6 000
A20M
1
20 000 20 000 3 000 3 000
A14M
1
14 000 14 000 2 000 2 000
A10M
1
10 000 10 000 1 500 1 500
A7M
1
7 000 7 000 1 000 1 000
A3.5M
1
3 500 3 500 500 500
A2M
1
2 000 2 000 300 300
A1.4M
1
1 400 1 400 200 200
A700K
1
700 700 100 100
A350K
1
350 250 50 35
A200K
1
200 100 30 15
A160K
1
160 60 23 8
A100K
1
110 10 16 1.5
BA100K
4
110 -- 16 --
G200K
2
-- 200 -- 30
G100K
2
-- 100 -- 15
G15K
2
-- 15 -- 2.2
BG15K
3
-- ±15 -- ± 2.2
1. All AXXXX RPTs support absolute, gauge and compound (negative) gauge modes.
2. All GXXXX RPTs are positive gauge mode only.
3. BG15K is bi-directional gauge from - 15 to + 15 kPa (- 2.2 to + 2.2 psi).
4. BA100K is a barometric range whose low point is 70 kPa absolute (10 psi).
