3. OPERATION
Page 41 © 2004-2007 DH Instruments, a Fluke Company
3.3.6.6 Freeze
PURPOSE
To activate the Freeze DISPLAY.
See Section 3.3.6, Principle.
OPERATION
To activate the Freeze DISPLAY press [DISPLAY], <6Freeze>. Pressing
<6Freeze> returns to the main run screen with the Freeze DISPLAY active.
With the Freeze DISPLAY active the main run screen is:
1. Pressure measured by active range of RPM4
when [ENT] was pressed (displays 0.00 by
default when Freeze DISPLAY is first
activated).
99.135 psi a zHi
F 99.2133
Pressing [ENT] causes the current pressure measured by the active RPM4 Q-RPT
to be captured and displayed.
If the pressure measurement unit, mode or range is changed while the Freeze
DISPLAY is active, the Freeze value defaults back to zero.
To go to a DISPLAY other than Freeze, press [DISPLAY] and make a new
DISPLAY choice (see Section 3.3.6).
3.3.6.7 Clean
PURPOSE
To activate the Clean DISPLAY.
See Section 3.3.6, Principle..
The AutoTest function (see Section 3.3.10) to AutoRange RPM4 based on
DUT characteristics and run an automated test sequence is accessed by
pressing [ENT] from the Rate run screen.
