PROLYTE ANALYZER
B. Manually move the probe arm until the sample probe hole is aligned with the
top chamber on the solutions valve.
▲ When the sample probe is aligned, DO NOT move the probe arm until the
probe motor installation is complete.
7 Place the locator into position. The locator should be seated inside the probe position sensor and
inside the mounting bracket slot.
8. Attach and slightly tighten the washer and screw at the top of the position locator. Do not fully
tighten the screw.
9. Align the probe position locator slot within the center of the optical switch. Gently move the
locator to the left and visually confirm the alignment. Refer to Figure P2 for correct alignment.
▲ Confirm that the sample probe hole is aligned with the top chamber on the solutions valve
before continuing.
10. When alignment is complete, fully tighten the probe position screw into place using a Phillips head
screw driver.
33
