8
860 Er Owner’s Manual
Assembly Instructions
screws and nuts, using a Phillips screwdriver.
3. Repeat the process of item 1 and 2 for the other side.
Step 5: : U Handlebar Assembly
1. Insert the hand pulse harness through the opening of the console mast and
out of the console mounting plate.
2. Assemble the handlebar onto the mount and insert and tighten the two M8 x
35mm screws using an Allen wrench. Be sure not to pinch the hand pulse
harness during this procedure, as this will damage the electronic console.
Step 6: Console Assembly
1. Connect both plugs, from main wire harness and hand pulse harness, to the
plug receptors on the backside of the console, taking care to install correctly
(see plug alignment marks).
WIRING HARNESS INSTALLATION HINT: Any excess wiring must be carefully
inserted (“stored”) back into the console mast before installing the console
onto the console mounting plate.
2. Fasten the console to the console mounting plate with the four M5 x 12mm
screws and washers, using a Philips screwdriver
Step 7: Transformer Assembly
1. Plug the transformer into plug receptor located on the rear/bottom side of the
middle case.
2. Plug the transformer output into power outlet. NOTE: Be sure to use right
transformer for your power outlet, 110V or 220V.
Step 8: Water bottle
1. Place the water bottle into the water bottle holder.
860erOM 6/20/06 8:42 PM Page 10
