Data field. The Data field for the message code 0x52 consists of the following:
QC
data
QC Record Sample
QC data
Batch No.
(ASCII string
6 characters)
EXPIRY DATE
ASCII
string 6
characters
H-VALMIN
L-VALMIN
H-VALMAX
L-VALMAX
BATCH No.: ASCII string of 6 characters. Identifies the production batch of the control
blood
EXPIRY DATE: string of 6 characters without terminator, “DDMMYY” where:
• “DD” = day of the month, from “01” to “31” ASCII.
• “MM” = Month of the year, from “01” to “12” ASCII.
• “YY” = Year of the century, from “00” to “99” ASCII.
H-VALMIN / L-VALMIN: Value lower than the acceptability range for the control blood,
represented in HEX-ASCII.
H-VALMAX / L-VALMAX: Value higher than the acceptability range for the control blood,
represented in HEX-ASCII.
QC Record Sample:
BarCode
(ASCII string
max 15
characters)
Terminato
r of the
Barcode
string
(0x10)
DATA
ANALYSES
ASCII
string 6
characters
TIME ANALYSES
String
ASCII 4
characters
VES
ASCII
string 4
characters
H-FLAGS
L-FLAGS
RACK ID
Strin
g
ASCI
I 4
characte
rs
POSITION
String
ASCII
2
characters
BARCODE: ASCII string with variable length, maximum of 15 characters allowed. This is
the barcode just as it is read by the Mini Cube Barcode Reader.
TERMINATOR: the string of barcodes terminates with the 0x10 byte. This is because the
length of this string is variable.
DATA ANALYSES: string of 6 characters without terminator, “DDMMYY” where:
• “DD” = day of the month, from “01” to “31” ASCII.
• “MM” = Month of the year, from “01” to “12” ASCII.
• “YY” = Year of the century, from “00” to “99” ASCII.
TIME ANALYSES: string of 4 characters without terminator, “hhmm” where:
• “hh” = hour of the day, from “00” to “23” ASCII.
• “mm” = Minutes, from “00” to “59” ASCII.
