XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 12
EVM – Typical, Maximum Output Power
EVM (25
℃
, max output power)
Standard Data rate EVM (dB)
802.11b
1 Mbps -40
2 Mbps -40
5.5 Mbps -38
11 Mbps
-36
802.11g
6 Mbps -18
9 Mbps
-20
12 Mbps -21
18 Mbps -22
24 Mbps -22
36 Mbps
-23
48 Mbps -25
54 Mbps
-26
802.11n
MCS 0 6.5/7.22 Mbps -19
MCS 1 13/14.44 Mbps
-21
MCS 2 19.5/21.67 Mbps -22
MCS 3 26/28.89 Mbps
-24
MCS 4 39/43.33 Mbps -25
MCS 5 52/57.78 Mbps
-25
MCS 6 58.5/65 Mbps -26
MCS 7 65/72.22 Mbps -28
