Digi XBee Manual

XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 76
ZigBee Explicit Transmit Packet
Frame Type: 0x11
This frame type is provided for software compatibility with other XBee modules and for sending
GPM requests. If neither of these is required, then frame type 0x20 is recommended for data
transmissions from this module. An example of a GPM request is given below:
API Packet
Frame Fields
Offset
Example
Description
Start
Delimiter
0 0x7E
Length
MSB 1 0x00
Number of bytes between the length and the
checksum
LSB 2
0x1C
API Frame
Specific Data
API Frame
Identifier
3 0x11
Frame ID 4 0x01
Correlates request with a later TX STATUS frame
(0x8B). If 0, no TX STATUS frame will be sent
64-bit source
address
5 0x00
Align IP address to low 32-bits of the field. The
other bytes are set to 0. IP address is in hex.
This example uses address 192.168.1.130
6 0x00
7 0x00
8 0x00
9 0xC0
10 0xA8
11
0x01
12 0x82
Reserved
13 0xFF
Unused placeholders
14 0xFE
15
0xE6
Dest Endpoint 16 0xE6 Digi Device Object
Cluster ID
17 0x00
Memory Access Cluster ID
18 0x23
Reserved
19
0xC1
Unused placeholders 20 0x05
21 0x00
Options 22 0x00
0x01 – Disable ACK
All other bits must be set to 0.
RF Data
23
0x00
Up to 1392 bytes of data
24 0x00
25 0x00
26 0x00
27
0x00
28 0x00
29 0x00
30 0x00
Checksum
31 0x50
Add this value to sum of bytes from byte 3 to
here such that result = 0xff.

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
