5.5 Access to CATRAX Plus after assembly
After is installed and assembled, access to the interior of the equipmentCATRAX Plus
can be done with the key that accompanies the equipment, in three ways:
5.5.1 Rear cover
1º Open the lock with the smaller key (clockwise)
2º Carefully raise the cover
3º Brag the cover backwards
As shown below:
5.5.2 Frontal cover
1º Unscrew the screws inside the turnstile that hold the cover
2º Unscrew the screws out of the cover
3º Pull the cover upwards
As shown below:
