digicon CATRAX Plus - Rear Cover; Frontal Cover

12
Pictogram’s acrylic
Rear stainless steel cover
Frontal cover
Rear cover
Colector box’s
socket kit
plus
plus
Then, assemble the upper panel’s rear cover. The image below shows the parts
corresponding to each phase.
Fiat washer M3, lock washer
M3 and hex nut M3
Frontal plastic
cover set
Frontal stainless
steel sheet
