Catrax Plus:
Gross weight Approxim. 40 kg (including package).
Distance between
arms
120 degrees
Electromagnets’
power
12 Vcc and 12 A
Sensors’ power 5 Vcc and 0.5 A
Power supply
(optional)
Input: 100 Vca and 240 Vca
Output: 12 Vca +-5% / 3 A
Dimensions: 35 x 51 x 105 mm
Distance between holes: 43 x 98 cm
Diameter of holes: 3.5 mm
Board with display Power: 6 to 24 Vcc / 100 mA
Turnstile consumption
(without anti-panic)
7W (stand-by)
20W (peak/forcing the arm)
Turnstile consumption
(with anti-panic)
15W (stand-by)
45W (peak/forcing the arm)
