digicon CATRAX Plus - Page 20

20
CN4 BOX SENSOR
1 LED anode
2 Box signal
3 GND
4 GND
CN5 ELECTROMAGNETS
(+) Electromagnet 1
(-) Electromagnet 1
(+) Electromagnet 2
(-) Electromagnet 2
CN6 OPTICAL SENSORS
Sensor 1 signal
LED 1 anode
Sensor 2 signal
GND
LED 2 anode
plus
INFORMATION:
-The cables of the optical sensors (CN6) and the electromagnets (CN5)
are provided alongside CATRAX Plus.
-The cable of the box sensor (CN4) is provided alongside the collecting
box kit (optional)
