DigiDesign DIGI 1 User Manual

Chapter 4: Connecting Your Studio 37
Studio Setup Diagrams
Your setup will differ depending on which of these systems you use. The illustrations that
follow show two typical home studio setups.
Digi 001 studio configuration with a mixer—Direct Outputs mode (see “Output Modes” on page 29)
Mics and
instruments
Mixer audio
inputs
Monitor
speakers
Mixer
stereo
outputs
Effects devices
Effects device
DAT recorder
S/PDIF
I/O
Analog inputs/
outputs 7-8
Analog
outputs 1-6
Analog
inputs 3-6
Mixer
channel
outs 1-4
Mixer
inputs 1-6
or tape
returns
Aux/Effects
sends/returns
& amplifier
Analog
outputs 1-6
